NABL Accredited · CC-2480 · Est. 2004 · Gujarat's Trusted Calibration Lab
NABL-accredited calibration for aspiration & suction pumps — surgical, portable, and regulated vacuum systems. ISO 10079 traceable, accepted by NABH, ISO 13485, and all hospital quality auditors.
0–760 mmHg
Range
±5 mmHg
Accuracy
ISO 10079
Standard
ISO 10079
Suction Pump Standard
NABL Accredited
CC-2480
— WHAT IS SUCTION PUMP CALIBRATION —
Imagine an operating theatre where a suction unit is delivering 20% less vacuum than its dial indicates — airway clearance during surgery becomes unreliable at the exact moment it matters most. A miscalibrated suction pump puts patient safety at direct risk.
Suction pump calibration compares the regulated vacuum level and flow rate of an aspiration unit against NPL-traceable vacuum references at multiple set points. Deviations are documented, the regulator adjusted where possible, and a NABL certificate issued confirming ISO 10079 compliance — accepted by NABH and ISO 13485 auditors.
Check
Vacuum level and flow rate tested at multiple set points against NPL-traceable vacuum reference.
Correct
Regulator and relief-valve adjustment performed; correction table issued where adjustment isn't possible.
Certify
NABL CC-2480 certificate issued with full as-found/as-left data and uncertainty statement.
— INSTRUMENTS COVERED —
Surgical, portable, and regulated vacuum aspiration systems across all makes and models.
Electric surgical aspirators calibrated for negative-pressure (vacuum) accuracy and regulated suction performance.
Vacuum regulator and gauge calibration at multiple set points against NPL-traceable vacuum reference.
Suction flow rate (L/min) measured at defined vacuum levels and compared to manufacturer-stated performance.
Regulator valve linearity, overflow protector, and pressure-relief function tested across the full operating range.
— OUR PROCESS —
Pump body, collection jar, tubing, overflow protector, filter, and switch inspected — incoming condition documented as-found.
Outlet blocked and pump run to measure maximum achievable vacuum using NABL-traceable vacuum reference gauge.
Pump set to regulated vacuum levels (e.g. -20, -40, -60, -80 kPa). Actual vacuum measured at each point and deviations recorded.
Suction flow rate measured at defined vacuum levels. Regulator adjusted where permitted; correction table issued otherwise.
Post-adjustment vacuum and flow readings verified at all points per ISO 10079. Expanded uncertainty calculated per ISO/IEC 17025.
NABL CC-2480 certificate with as-found/as-left data, uncertainty (k=2), and ISO 10079 traceability issued within 24 hours.
— STANDARDS & COMPLIANCE —
Every suction pump calibration is performed under ISO 10079, with full traceability to NPL national standards. Our certificates satisfy all hospital accreditation and regulatory audit requirements.
ISO/IEC 17025
NABL Accreditation Standard
ISO 10079
Suction Equipment Standard
IEC 60601-1
Medical Equipment Safety
ISO 13485
Medical Device QMS
NABH
Hospital Accreditation
WHO GMP
GMP Compliance
NPL / NIST
Traceable Reference
ISO 9001:2015
Quality Management
Prism holds NABL CC-2480 under ISO/IEC 17025:2017, recognized under the ILAC MRA agreement. Our biomedical calibration certificates are valid for WHO GMP, FDA, NABH, and all audit purposes.
— NON-NABL CALIBRATION —
For routine maintenance, bulk calibration, or facilities not needing NABL certification — Prism offers cost-effective non-NABL calibration with the same trained engineers and traceable references.
All non-NABL jobs use the same NPL-traceable references — only the certificate type differs.
Non-NABL jobs completed faster — ideal for urgent maintenance or large bulk batches.
Priced lower than NABL — right choice for internal checks and non-audit use cases.
Available at our Ahmedabad lab and as onsite service across Gujarat — same team, same quality.
— AREAS WE SERVICE —
NABL-certified engineers travel to your facility across Gujarat — hospital, pharma, or laboratory onsite service.
Why Choose Prism
Since 2004, every NABL biomedical certificate issued by Prism has been accepted by WHO GMP, FDA, NABH, and ISO auditors — no rejections, no rework.
